XHDL Series High Current Generator for CT Ratio & Temperature Rise Test

XHDL Series High Current Generator for CT Ratio & Temperature Rise Test

Rincian produk:
Tempat asal: Xi'an, Shaanxi, Cina
Nama merek: XZH TEST
Sertifikasi: ISO,CE
Nomor model: Seri XHDL
Informasi Rinci
Tempat asal:
Xi'an, Shaanxi, Cina
Nama merek:
XZH TEST
Sertifikasi:
ISO,CE
Nomor model:
Seri XHDL
Menyoroti:

High Light

Menyoroti:

high current generator for CT test

,

AC DC hipot tester with warranty

,

temperature rise test equipment

Trading Information
Kuantitas min Order:
1 buah
Harga:
Dapat dinegosiasikan
Kemasan rincian:
kemasan kayu
Waktu pengiriman:
8-10 hari
Syarat-syarat pembayaran:
T/T
Menyediakan kemampuan:
2000unit/tahun
Deskripsi Produk
Product Overview

The XHDL Series High-Current Generator employs the principles of electromagnetic induction, high-permeability magnetic materials, and an innovative structural design. It can be custom-manufactured to meet specific user requirements.

Key Features
  •   low coil leakage flux
  •   excellent ampere-turn balance
  •   strong resistance to electromagnetic forces
  •   safety and reliability
  •   stable performance
  •   ease of operation
  •   high accuracy
  •   light weight
  •   compact dimensions
Technical Specifications
  • ★ Output Current: 200A – 20,000A
  • ★ Output Voltage: 5V / 8V / 10V (Select one)
  • ★ Accuracy Class: 0.2 / 0.5 / 1.0 / 1.5
  • ★ Power Supply: 220V±10% / 380V±10%, 50Hz±5%
  • ★ Operating Environment: Temperature: -10°C – 50°C; Humidity: RH < 90%
  • ★ Weight: 35 kg – 400 kg
  • (Can also be manufactured according to specific user requirements)
